SCN-1000W Single Output Switching Power Supply

1. High reliability, low ripple
2. Switch input voltage range choice
3. Protection characteristics: short circuit/overload/pressure/thermal
4. Built-in distance open/shutdown and voltage compensation signal interface
5. Has the parallel function
6. Built-in dc electric fan forced air cooling
7. One year warranty
8. Size : 291*132*68mm (L*W*H)

OnLine Service:

E-mail Us PDF Download
vantoele 75606132
【Prev Products】 【Next Products】

Description

SCN-1000W AC to DC CCTV Switch Power Supply SMPS

Model Performance

SCN-1000-12

SCN-1000-13.5

SCN-1000-15

SCN-1000-24

SCN-1000-27

SCN-1000-48

DC Output Volta

12V

13.5V

15V

24V

27V

48V

Output voltage tolerance(Note 2)

±1%

±1%

±1%

±1%

±1%

±1%

Rated output current

80A

74A

66A

42A

37A

20A

Output current range

0-80A

0-74A

0-66A

0-42A

0-18A

0-10A

Ripple and noise(Note 3)

240mVp-p

240mVp-p

240mVp-p

240mVp-p

200mVp-p

300mVp-p

Inlet stability(Note 4)

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

Load stability(Note 5)

±1%

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

DC output power

960W

999W

990W

1008W

999W

960W

Efficiency

84%

84%

83%

85.5%

86.5%

87%

DC voltage adjustable range

10-13.2V

12-15V

13.5-18V

20-26.4V

24-30V

41-56V

Input voltage range

88~132VAC/176~264VAC CHOOSE BY SWITCH 47~63Hz; 254~370VDC

Input current

7A/115V 3.5A/230V

Surge Current

0.95/100~240VAC

Leakage Current

18A/115V 36A/230V

Overload protection

<3.5mA/240VAC

over-voltage protection

105%~135% type:FOLDBACK cut off output reset:Automatic recovery

High temperature protection

13.8~16.2V

15.5~18.2V

18~21V

27.6~32.4V

31~36.5V

57.6~67.2V

temperature coefficient

RTH1 OR RTH2>=55°C FAN ON,<=45°C FAN OFF,>=70°C cut off output

Start-up,upper,rentention time

±0.03%°C(0~50°C)

shock resistance

1.5s,50ms,20ms

Withstand

10~500Hz,2G 10min./1circle,time:60min.,axes

Insulation Resistance

Input to Output Isolation:3KVAC,input&shell:1.5KVAC output &shell:0.5KVAC

work Temperature/

humidity

Input to Output Isolation,,input&shell, output &shell:500VDC/100M Ohms

Storage Temperature, temperature

-10°C~+50°C,20%~90%RH

Outline dimension

-20°C~+85°C,10%~95%%RH

Weight

291*132*68mm

Safety standards

2.65Kgs

EMC Standard

UL1950,TUV EN60950

ModelPerformance

CISPR22(EN55022),IEC1000-42,3,4,5,6,8,11 IEC100-3-2

SCN-1000W AC to DC CCTV Switch Power Supply SMPS Packing

SCN-1000W AC to DC CCTV Switch Power Supply SMPS Packing ShowSCN-1000W AC to DC CCTV SMPS FAQ

Q:1.How do you control the products' quality?

A:Auto inspection machine and manual testing together before packing.


Q:2.What's your payment term?
A:We usually accept T/T(30% deposit,the balance before delivery.)
Samples cost can be paid by Western Union,MoneyGram

Q:3.Would you accept to use our logo?
A:If you have good quantity,we can make OEM for you.

Q:4.Can I get a sample for reference?
A:We provide free samples for testing,you only need to pay the courier cost.

Q:5.What is your MOQ?
A:The MOQ can be only 1 piece.

Q:6.What is your delivery time?
A:Usually it takes 7-25 working days depends on items and quantity.

Q:7.What is your warranty time of the products?
A:24 months
